JideTech POE 4K 4CH IP 8CH NVR Security Camera System (NK2-4H-8MP)
JideTech POE 4K 4CH IP 8CH NVR Security Camera System (NK2-4H-8MP)
Key Features:
- 8 million pixels, enjoy ultra-high-definition picture quality
- POE over power supply: the network cable is directly connected, just one wire meets the requirement of network + power supply, and the installation is convenient
- H.265+ high compression ratio, reducing storage space and transmission bandwidth
- Automatically add IPC, support plug and play
- Support ONVIF protocol; can connect to third-party NVR and platform, also can connect to third-party IPC
- Infrared white light dual-light design, supports three adjustable night vision modes to achieve full color at night
- Active defense, when someone breaks into the warning area, the equipment will sound and light alarm
- Intelligent humanoid detection, filtering false positives, and accurately protecting your safety
- Built-in high-sensitivity MIC and speaker, support two-way voice intercom
- Support multi-channel remote monitoring of mobile phones and PC clients, and view the live scene anytime, anywhere
Specifications:
| PoE NVR | |
| Processor | Industrial embedded microcontroller |
| Operating system | Embedded LINUX operating system |
| Picture decoding | 720P，960P，1080P ，3MP，4MP,5MP，8MP vedio encoding |
| Video interface | 8*720P/960P/1080P/3MP/4MP/5MP/8MP |
| Video output | 1080P@60fps，4K@30fps (1H VGA output, 1H HDMI output） |
| Video code | Timing video、motion detection video |
| Video storage | SATA hard disk*1, Maximum 6TB |
| Video playback | 1*8MP playback；1*5MP playback；2*3MP playback； 8*1080P playback |
| Backup mode | USB backup and Network backup |
| Network protocol | TCP/IP,HTTP,DHCP,UDP,RTP,RTSP,FTP,NTP,P2P |
| Mobile Phone app | EseeCloud（Android, IOS）, Tuya is optional |
| Network interface | 1*RJ45 10M/100Mbps adaptive Ethernet port |
| POE | 4/8* PoE IEEE802.3af/RJ45 10M/100Mbps adaptive Ethernet port |
| USB | 2*USB 2.0 |
| Audio output | 1*3.5mm audio interface (support HDMI audio output) |
| Audio intput | |
| Power | DC 48V /2A |
| Power Consumption | 4H≈30W 8H≈58W |
| Working temperature | -10℃~＋55℃ |
| Working environment | Indoor |
| IP Camera | |
| Sensor | 1/2.5” CMOS Sensor，Color: 0.1 Lux， Black/White: 0.01 Lux |
| Vedio coding | H.264/H.265 |
| Maximum resolution | Main stream：3840x2160@15fps；sub-stream：720x576@15fps |
| Len | 4mm |
| Function | Support motion detection、JPEG screenshot |
| Night vision fill light | IR light（20M) |
| Day and night | IR-CUT IR Filter |
| Audio | Optional, support voice intercom/built-in microphone |
| POE | PoE IEEE802.3af |
| Interface | 1*RJ45 10/100M adaptive Ethernet port |
| Protocol | Support RTSP，DHCP，ONVIF，N1 private protocol |
| Power | DC 12V /1A / PoE |
| Dimension of box | 320*180*320MM |
| Qty/CTN | 4 Set/ CTN, |
| Dimension of Carton | 660*380*330MM |
| Installation | Universal |
| Working environment | Indoor/outdoor |
| Protection grade | IP66 |
