JideTech P22 PLUS 12MP 23X/30X PoE PTZ IP Camera with ONVIF Absolute Positioning

P22 PLUS 12MP 23X / 30X PoE PTZ IP Camera

Professional 12MP Surveillance | Optical Zoom | ONVIF Absolute Positioning | RTSP / RTMP | Time-lapse | API / SDK

The JideTech P22 PLUS is a professional outdoor 12MP PoE PTZ IP camera available in two optical zoom versions: 23X and 30X. Designed for CCTV installers, security system integrators and industrial monitoring projects, it combines ultra-high-resolution video, precision PTZ positioning, advanced night vision and flexible third-party software integration.

Both versions support ONVIF Absolute Move, RTSP, RTMP live streaming, time-lapse configuration, AI detection, automatic tracking, H.265+ compression and API/SDK integration. Choose the 23X model for cost-effective high-resolution surveillance or upgrade to the 30X version for Sony IMX577 imaging, up to 30fps and longer-range IR illumination.

Key Features

• 12MP Ultra HD: 3840 × 3104 or 4000 × 3000 resolution
• 23X / 30X Optical Zoom: Two selectable models
• ONVIF Absolute Positioning: 0.1° high-resolution movement commands
• PTZ Speed: Up to 70°/second
• 360° Endless Pan: Precision remote movement control
• Day & Night Surveillance: Full-color and infrared night vision
• Long-Range IR: Up to 300m (23X) or 500m (30X)
• Time-lapse: Configurable using AjSearchTools
• Professional Protocols: ONVIF, RTSP, RTMP, HTTP, HTTPS and FTP
• Custom Integration: API and SDK support
• AI Surveillance: Human and vehicle detection, intelligent tracking and event alerts
• Outdoor Ready: IP66, PoE+ IEEE 802.3at

1. Choose Your Camera: 23X or 30X Optical Zoom

The P22 PLUS is available in two 12MP optical zoom configurations. Both models use the same professional PTZ platform, but offer different image sensors, frame rates, focal lengths and infrared illumination distances.

Select your preferred Optical Zoom version from the product options above to view the corresponding price.

2. True 12MP Ultra HD — Actual Daytime Video Quality

Both P22 PLUS models capture 12MP images, providing additional detail for wide-area surveillance, remote observation and recorded video review.

The 23X version captures up to 3840 × 3104 at 15fps, while the 30X model delivers up to 4000 × 3000 at 30fps. The following surveillance image illustrates the real-world 12MP image quality available from the camera series.

High-resolution imaging is suitable for outdoor construction sites, industrial facilities, parking lots, building exteriors and large commercial properties.

3. 23X / 30X Optical Zoom — From Wide Views to Distant Details

Optical zoom is one of the P22 PLUS camera's most important advantages. Unlike digital zoom, which enlarges existing pixels, optical zoom changes the physical focal length of the lens to provide a closer view of distant subjects.

23X Optical Zoom — 4.5–103mm

The 23X version supports motorized autofocus and a horizontal field of view ranging from 68.8° to 3.4°. It is designed for surveillance applications requiring flexible coverage and moderate-to-long-range observation.

30X Optical Zoom — 4.3–129mm

The 30X version extends the focal length to 129mm and narrows the horizontal field of view to approximately 2.7° at maximum optical zoom, helping operators inspect more distant areas.

Both models also support up to 10X digital zoom and remote PTZ control. Actual object recognition and identification distances depend on target size, light levels, atmosphere and camera stability.

4. ONVIF Absolute Positioning — Precise and Repeatable PTZ Commands

The JideTech P22 PLUS supports ONVIF absolute PTZ movement, making it suitable for professional security projects that require software-controlled pan and tilt positioning.

Instead of relying only on manual movement or relative PTZ commands, a compatible video management platform can send absolute movement commands to supported pan/tilt coordinates.

• ONVIF Absolute Move supported on both versions
• High-resolution movement command: 0.1°
• Interface positioning resolution: 0.0005°
• 360° endless horizontal pan
• -15° to 90° tilt range
• Maximum pan and tilt speed: 70°/second
• 128 preset positions
• Compatible with supported software-based PTZ control

Watch Our Absolute Positioning Demonstration

See how absolute positioning operates in the following JideTech demonstration video.

Ideal for: VMS integration, automated security patrols, preset-based monitoring, surveillance command centers and custom industrial camera control systems.

Note: Command resolution and software coordinate display resolution do not independently establish physical pointing accuracy. Confirm positioning performance for precision-critical applications.

5. Real Day & Night Performance — Full-Color and Infrared Night Vision

The P22 PLUS supports infrared and white-light supplemental illumination, automatic day/night switching and image adjustment for outdoor surveillance after dark.

The 23X model provides IR illumination up to 300m, while the 30X model provides IR illumination up to 500m, according to the model specifications. These values refer to the rated illumination range, not guaranteed human identification distance.

Actual 12MP Full-Color Night Vision — Sample 1

Actual 12MP Full-Color Night Vision — Sample 2

Actual Black & White IR Night Vision

Night vision capabilities: Automatic IR-cut control, infrared illumination, white-light supplementation, WDR/HDR support and 2D/3D digital noise reduction.

The samples illustrate the P22 PLUS product series. Lighting and image performance depend on the selected version and recording environment.

6. Time-lapse Function — Long-Term Construction and Site Monitoring

The P22 PLUS supports time-lapse configuration using AjSearchTools, providing additional options for projects requiring periodic visual documentation.

Time-lapse workflows are especially useful for construction site observation, project progress review, industrial site changes and long-term facility monitoring.

Contact JideTech for supported capture settings, recording intervals and integration requirements for your time-lapse project.

7. AI Intelligent Detection, Auto Tracking and Event Recording

The P22 PLUS provides intelligent security detection functions designed to support proactive monitoring and automatic event recording.

Intelligent Detection Features

• Human detection
• Vehicle detection
• Motorcycle, e-bike and bicycle target detection
• Motion detection
• Intrusion and line-crossing detection
• Off-duty detection
• Passenger flow statistics
• Humanoid tracking and automatic PTZ cruise tracking

Event and Alarm Linkage

Supported event actions include local recording, snapshots, email upload, FTP upload, sound alarms and alarm notifications. Availability depends on the selected rule and system configuration.

8. ONVIF, RTSP, RTMP, API & SDK — Built for System Integration

Unlike surveillance devices designed only for proprietary app viewing, the JideTech P22 PLUS supports multiple professional integration protocols and software interfaces.

ONVIF 2.4 — NVR and VMS Compatibility

Support for ONVIF Profiles S and G allows integration with compatible NVR and video management systems. ONVIF absolute PTZ commands enable additional positioning functions where the receiving software supports them.

RTSP — Third-Party Video Streaming

The camera provides RTSP network video streams for compatible recorders and third-party video applications.

RTMP — Live Streaming

RTMP push streaming enables integration with compatible RTMP receiving servers and supported live streaming applications. Configure the destination and stream settings according to the requirements of the receiving platform.

API and SDK — Custom Software Development

JideTech provides API/SDK integration support for system developers and security solution providers. Available functions and development documentation should be confirmed according to project requirements.

Professional integrations may also use supported Hikvision and Dahua private protocols. Please verify individual integration functions before large-scale deployment.

9. Shared PTZ, Power, Network and Storage Specifications

10. Frequently Asked Questions

What is the difference between the 23X and 30X models?

Both models offer 12MP resolution, ONVIF absolute positioning, PTZ control and professional network integration. The 23X model uses an OS12D40 sensor, supports up to 15fps and has an IR illumination range of up to 300m. The 30X model uses a Sony IMX577 sensor, supports up to 30fps and has an IR illumination range of up to 500m.

Do both versions support ONVIF Absolute Positioning?

Yes. Both 23X and 30X versions support ONVIF absolute positioning and high-resolution movement commands with 0.1° command resolution.

Can I connect the camera to a third-party NVR?

Yes. Both versions support ONVIF Profile S/G and RTSP for compatible third-party recording and video management solutions.

Does the camera support RTMP live streaming?

Yes. Both models support RTMP push streaming for compatible receiving servers and applications.

Can the camera support time-lapse monitoring?

Yes. Time-lapse configuration is available through AjSearchTools. Please confirm the required capture intervals and workflow before deployment.

Which version is better for long-range night surveillance?

The 30X version is the better option when longer optical focal length and a higher specified IR illumination range are required. However, 500m IR illumination does not guarantee identification of a person or vehicle at 500m.

Are these Wi-Fi or 4G cameras?

No. These versions are wired Ethernet PoE PTZ IP cameras. Built-in Wi-Fi and 4G connectivity are not specified.

Can JideTech support OEM/ODM and API/SDK integration?

JideTech supports OEM/ODM project discussions and API/SDK integration inquiries. Please provide the required functionality, deployment quantity and technical requirements for evaluation.

11. Factory Direct — B2B CCTV and OEM/ODM Projects

JideTech provides professional IP surveillance cameras for CCTV distributors, system integrators, security engineering companies and industrial monitoring projects worldwide.

Contact us for 23X and 30X model quotations, volume pricing, project evaluation samples, API/SDK documentation and OEM/ODM requirements.

Manufacturer: Shenzhen JideTech Development Co., Ltd.

Website: www.jidetech.com

WhatsApp: +86 189 2933 7423

Choose your preferred optical zoom version above or contact our sales team for a project quotation.
