JideTech 8MP 36X Zoom Vechicle PTZ Camera with 1000m laser (LC002-36X-8MP)
JideTech 8MP 36X Zoom Vechicle PTZ Camera with 1000m laser (LC002-36X-8MP)
Key Features
- The first independent defogging defrosting module, solve the camera and lens fogging
- High-quality heating parts are used in the camera housing, so that the whole housing can work together to form an effective antifogging and defogging
- PTZ adopts the integrated upper and lower structure so that the PTZ and infrared housing will not bump and dislocate.
- PTZ standard with the original regulator module, filter the vehicle transient current instability, so that PTZ remains stable
Night Vision Supplement:
Adopts imported 808nm laser to achieve synchronous zoom, angle adjustable or automatically adjusted according to the camera multiple, laser spot angle of 1 ° to 50 °, laser 5W optional, night vision 500m
HD IP:
PTZ support mainstream megapixel digital high-definition movement and HD SENSOR HD picture capture, compatible with mainstream HD platform and seamless docking, the maximum support 1080P output, support for dual-stream and high-definition capture, support IE browser
Application:
police mobile law enforcement / fire emergency command / 120 emergency command system / road mobile patrol / urban management law enforcement / special vehicle mobile inspection
Specification
|
PTZ Function |
|
|
Pan preset speed |
100°/s |
|
Tilt preset speed |
80°/s |
|
Pan control speed |
0°~60°/S |
|
Tilt control speed |
0°~40°/S |
|
Pan range |
360°endless rotation |
|
Tilt range |
+60° ~ -90° |
|
Preset positions、Tracking |
256 positions 6 tracking |
|
Control Way |
RS485, Built-in 16 protocol, Baud Rate from 2400Bps to 19200Bps optional |
|
Relative Humidity |
Less than 90% |
|
IP Grade |
IP66 |
|
Working Temperature |
-35° ~ +55° |
|
Power Consumption |
DC10.8V-DC18V |
|
Impact resistance requirements |
≥4G |
|
Wiper |
Support |
|
Installation |
Variety of installation according to the environment |
|
Weight |
6kg |
|
Camera
|
Image Sensor |
1/1.8” Progressive Scan CMOS |
|
Minimum Illumination |
Color:0.0005 Lux @ (F1.35, AGC ON); B/W:0.0001Lux @ (F1.35, AGC ON) |
|
|
Shutter |
1/25s to 1/100,000s; Support delayed shutter |
|
|
Aperture |
PIRIS |
|
|
Day/Night Switch |
ICR cut filter |
|
|
Digital Zoom |
16x |
|
|
Lens
|
Focal Length |
6.4~256mm, 40x Optical Zoom |
|
Aperture Range |
F1.35-F4.6 |
|
|
Horizontal Field of View |
60.9-2.05° (wide-tele) |
|
|
Minimum Working Distance |
100mm-1500mm (wide-tele) |
|
|
Zoom Speed |
Approximately 4.5s(optical, wide-tele) |
|
|
Compression Standard
|
Video Compression |
H.265 / H.264 |
|
H.265 Type |
Main Profile |
|
|
H.264 Type |
BaseLine Profile / Main Profile / High Profile |
|
|
Video Bitrate |
32 Kbps~16Mbps |
|
|
Audio Compression |
G.711a/G.711u/G.722.1/G.726/MP2L2/AAC/PCM |
|
|
Audio Bitrate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/16-64Kbps(AAC) |
|
|
Image（Maximum Resolution：3840×2160）
|
Main Stream |
50Hz: 25fps (3840×2160, 1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (3840×2160, 1920 × 1080, 1280 × 960, 1280 × 720) |
|
Third Stream |
50Hz: 25fps (704 x 576); 60Hz: 30fps (704 x 576) |
|
|
Image Settings |
Saturation, Brightness, Contrast and Sharpness can be adjusted via the client-side or browse |
|
|
BLC |
Support |
|
|
Exposure Mode |
AE / Aperture Priority / Shutter Priority / Manual Exposure |
|
|
Focus Mode |
Auto Focus / One Focus / Manual Focus / Semi-Auto Focus |
|
|
Area Exposure / Focus |
Support |
|
|
Defog |
Support |
|
|
Day/Night Switch |
Automatic, manual, timing, alarm trigger |
|
|
3D Noise Reduction |
Support |
|
|
Picture Overlay Switch |
Support BMP 24-bit image overlay, customizable area |
|
|
Region of Interest |
Support three streams and four fixed areas |
|
|
Network |
Storage Function |
Support micro SD / SDHC / SDXC card (256g) offline local storage, NAS (NFS, SMB / CIFS support) |
|
Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,RTP,RTSP,RTCP,NTP,SMTP,SNMP,IPv6 |
|
|
Interface Protocol |
ONVIF(PROFILE S,PROFILE G) |
|
|
Intelligent Calculation |
Intelligent Calculation |
1T |
|
Interface |
External Interface |
36pin FFC (Network port, RS485, RS232, CVBS, SDHC, Alarm In/Out |
|
General |
Working Temperature |
-30℃~60℃, humidity≤95%(non-condensing) |
|
Power supply |
DC12V±10% |
|
|
Power consumption |
2.5W (ICR, 4.5W MAX) |
|
|
Dimensions |
145.3*67*77.3mm |
|
|
Weight |
607g |
Laser Parameter
|
Illuminating distance |
1000m |
|
Zoom range |
1-50° Auto Zoom |
|
Optical power |
5W |
|
Wavelength |
808nM |
|
Fill light effect |
Excellent spot uniform,uniform beam intensity, speckle free |
|
stability |
lifetime up to 20000hrs |
