Specifications:
| Pan-Tilt | |
| Rotation speed | Pan 0.1°~60°/S |
| Tilt 0.1°-60°/S | |
| Pan | 360° |
| Tilt | 90° |
| Preset | 128*preset positions, can be edited |
| Power-off position memory | Support |
| Guard | Support |
| Left-to-right scan | Support 1 group |
| Cruise | Support 2 group |
| Humanoid tracking | Support |
| Vehicle identification | Support |
| IP Camera | |
| Sensor | 1/2.8” IMX 415 CMOS Sensor+SSC338 |
| Vedio coding | H.264/H.265 |
| Audio coding | G.711 coding standard |
| Maximum resolution | Main stream: 3840×2160,3072×2048,2592×1944,2560×1440,2304×1296@20fps，1920×1080 1280×720@60fps； Sub stream：720×480,D1,VGA,640×360@30fps； |
| Len | 18X optical zoom lens(F=5.3~96mm) |
| White balance | Auto |
| Noise reduction | 2D/3D digital noise reduction |
| Strong light suppression | Support |
| Wide dynamics | Support |
| Back light compensation | Support |
| Defog | Support |
| OSD character overlay | Support |
| Privacy mask | Support |
| Intelligent Detection | Motion detection;humanoid detection;vehicle identification;area intrusion;alarm push(mobile phone APP, SMTP, FTP) |
| Night vision fill light | Infrared light (80~150M) |
| Audio | Support voice intercom/built-in microphone and speaker |
| SD Card | Support（256G Max） |
| Internet | |
| Interface | 10/100M RJ45 Network interface |
| POE | Optional (POE 48V-52V IEEE 802.3af standard） |
| Network protocol | TCP/IP，HTTP，NTP，DHCP，UDP，SMTP，RTP，RTSP，ARP，DDNS，DNS，P2P |
| ONVIF protocol | Standard ONVIF2.4 |
| Network security | IP address filtering; Access policy; RTSP certification; Account verification |
| Web | Support, plug-in requirement: IE9+ |
| APP | AC18pro（Android, IOS） |
| Other | |
| Power | 12V/3A (MXA 18W) |
| Reset Key | Support |
| Power consumption | 6W（18W fill light on） |
| Dimension of box | 23CM*17CM*29CM |
| Weight of box | 1.9KG/Pcs |
| Qty/CTN | 8 |
| Dimension of Carton | 48CM*36CM*61CM |
| G.W CTN | 16.2KG |
| Installation | Wall mounted |
| Working temperature | 0℃ -＋50℃ |
| Working humidity | 10%－90% |
| Working environment | Outdoor |
| Protection grade | IP66 (Outdoor) |
